MC55v

Multiscan MC55v

Multiscan MC55v Automatic Card Reader
MC55v AUTOMATIC CARD READER

MULTISCAN MC55v captures barcodes in plastic cards or in any other kind of stiff material such as cardboard, metal and any other on which barcodes can be printed.

MULTISCAN MC55v can count and/or read cards and arrange batches of a certain number of cards.

MULTISCAN MC55v can add a data field through the whole batch at once. Data from read cards is sent to a PC to be recorded and processed. It reads the most frequent linear barcodes. It is an accurate and important tool for the effective control of this kind of values of increasing diffusion in financial and commercial activities.

Technical
  • Automatic feeding of different kinds of cards
  • Adjustable document separation according to thickness.
  • Automatic error feeding detection.
  • Reading speed:300, 450 barcoded cards/m.
  • Host communicationType: RS232 (standard)
  • Feeding tray capacity: up to 120 cards (0.8 mm thick)
  • Reception tray capacity: up to 120 cards (0.8 mm thick)
Barcode
  • Readable symbologies: Code 39, Code 128, I2/5, Codabar, UPC/EAN (standard symbologies).
  • Readable number of codes: 6 codes/ piece
  • Readable digits: 62 chars./ code
  • Maximum code length: 4.5" (114mm)
  • Minimum code height: 1/ 2" (12mm)
  • Maximum code density: 10 mils.
Dimensions
  • Height: 300 mm (11.8")
  • Width: 410 mm (16.1")
  • Depth: 310 mm (12.2")
  • Weight: 10.5 Kg. (23 lbs.)
  • Footprint: 330 mm (13") [width] x 250 mm (9.8") [depth].
Documents Size
  • Minimum size 44 mm (1.75") x 76 mm (3")
  • Maximum size 127 mm (5") x 152 mm (6")
  • Card thickness: 0.5 mm up to 3 mm.
